The Blue-Point ALIGNMENT LIFT – SAL 12K is a professional professional workshop equipment for safe and efficient workshop servicing, featuring lifts straight up with no for or aft movement
| Specification | Details |
|---|---|
| Max Capacity (lbs) | 12,000 |
| Overall Length (mm) | 6,147 - 7,468 |
| Overall Width (mm) | 2,286 |
| Width Between Runways (mm) | 1,016 |
| Four Wheel Alignment Wheelbase (mm) | 2,260 - 4,010 |
| Two Wheel Alignment Wheelbase (mm) | Up to 4,190 |
| Platform Length (mm) | 4,550 |
| Platform Width (mm) | 610 |
| Platform Raised Height (mm) | 1,778 |
| Platform Lift / Lower Time | 45 - 95 seconds |
| Hydraulic Oil Specification | ISO 32 / 46 10WT |
| Air Supply Required | 6 - 9 bar |
| Shipping Weight (kg) | 3,000 |
| Power Supply | 220V 1Ph 50/60Hz; 380V 3Ph 50Hz |
| Installation Recommendation | Flush Mount |
| Optional Accessories | Roller jack |
